Customizable Shapes & Sizes of LiPo Battery
LiPo batteries do not require rigid metal casings; they are instead encased in flexible, lightweight pouches that can be shaped to fit the specific design requirements of the device they power. This allows for lipo batteries that are not just rectangular but can be curved or ultra-thin, enabling manufacturers to create devices with innovative, ergonomic designs that conform to specific spaces within products.
LiPo Battery LP504388 3.7V 2200mAh
Battery Type |
1S LiPo Battery |
Part Number |
LP504388 / 504388 |
Voltage @ Capacity |
3.7V @ 2200mAh 8.14Wh |
Protection Circuit |
S-8261ABMMD-G3MT2x |
Thermistor (NTC) |
- |
Wires |
UL1571 AWG24 50mm x 2 |
Connector |
- |
Dimension |
89 x 43 x 5.0mm |
Charge Current |
1.0-2.0A |
Discharge Current |
1.0-2.0A |
Working Temperature |
-20°C to +45°C |
More Details |
|
More LiPo Batteries |
LiPo Battery LP112540 3.7V 1100mAh
Battery Type |
1S LiPo Battery |
Part Number |
LP112540 / 112540 |
Voltage @ Capacity |
3.7V @ 1100mAh 4.07Wh |
Protection Circuit |
S-8261ABMMD-G3MT2x |
Thermistor (NTC) |
- |
Wires |
UL1007 AWG24 50mm x 2 |
Connector |
JST PHR-2(B) |
Dimension |
41 x 25 x 11.0mm |
Charge Current |
1.0-2.0A |
Discharge Current |
1.0-2.0A |
Working Temperature |
-20°C to +45°C |
More Details |
|
More LiPo Batteries |
LiPo Battery LP353283 3.7V 930mAh
Battery Type |
1S LiPo Battery |
Part Number |
LP353283 / 353283 |
Voltage @ Capacity |
3.7V @ 930mAh 3.441Wh |
Protection Circuit |
S-8261ABMMD-G3MT2x |
Thermistor (NTC) |
- |
Wires |
UL1571 AWG24 50mm x 2 |
Connector |
- |
Dimension |
84 x 32 x 3,5mm |
Charge Current |
465mA - 930mA |
Discharge Current |
465mA - 930mA |
Working Temperature |
-20°C to +45°C |
More Details |
|
More LiPo Batteries |
LiPo Battery LP113646 3.7V 2200mAh
Battery Type |
1S LiPo Battery |
Part Number |
LP113646 / 113646 |
Voltage @ Capacity |
3.7V @ 2200mAh 8.14Wh |
Protection Circuit |
S-8261ABMMD-G3MT2x |
Thermistor (NTC) |
- |
Wires |
UL1571 AWG22 50mm x 2 |
Connector |
JST ACHR-02V-S (A) |
Dimension |
46 x 36 x 11.0mm |
Charge Current |
1.0 - 2.0A |
Discharge Current |
2.0 - 3.0A |
Working Temperature |
-20°C to +45°C |
More Details |
|
More LiPo Batteries |
LiPo Battery LPHD5735062 3.7V 1000mAh 35C
Battery Type |
1S LiPo Battery |
Part Number |
LPHD5735062 / 5735062 |
Voltage @ Capacity |
3.7V @ 1000mAh 3.7Wh |
Protection Circuit |
- |
Thermistor (NTC) |
- |
Wires |
UL1571 22AWG 50mm x 2 |
Connector |
- |
Dimension |
63 x 35 x 5,7mm |
Charge Current |
2.0A - 3.0A |
Discharge Current |
35A - 70A |
Working Temperature |
-20°C to +45°C |
More Details |
|
More LiPo Batteries |
